Tatze Pedals Mc-Air CrMo4

Before ordering, please contact us. Thank you

Delivey time: 2-3 work days

Pedals MC-AIR Cr-Mo | black silver

Race Approved Flat Pedal!

maximum grip!

The MC-AIR with CrMo axle is an extremely potent flat pedal. 14 PINs with targeted cantilever provide enormous grip and a particularly rich connection between pedal and shoe. The two-row PINs on the inside provide enough grip, even if the shoe is placed a little further out.

for sure!

The large platform with 107x98x16mm (LxWxH) combines a secure stand with excellent lateral and ground clearance. The beveled front with stealth baffle corners allows the pedal to slide over obstacles and prevents dirt from collecting in the pedal.

innovative!

When relieving pressure, for example to take the leg on the inside of the curve off the pedal, a targeted rotational resistance ensures that the pedal does not continue to rotate independently. This prevents unpleasant surprises from a vertical pedal. If you want the maximum efficiency of a very lightly rotating pedal, you can quickly and easily remove the built-in resistance ring.

high quality stored and durable !

When it bearing , the MC-AIR leaves nothing to chance. A double-sealed and very wide needle bearing, a double-sealed industrial bearing and a double seal make the MC-AIR particularly durable and resistant.

Developed and tested in Tyrol / Austria!

Technical specifications:

intended use : Tour, Trail, Enduro, Alpen-X, Freerride, Downhill

Body material: 6061 T6 aluminum

axle material: Cr-Mo4 CNC machined

Material pins: steel

Height: 16.5 mm (without pins)

Pedal body: 107 x 98 mm

Number of pins: 14 pins per pedal side

bearing : double sealed needle and industrial bearing per pedal

Seal: double seal on the crank side + end cap on the pedal end

Max. Driver weight: no weight limit

Color: black / silver

Weight according to the manufacturer: 406g

Weight weighed: 404.7g

Scope of delivery:

1x pair of Paw pedals MC-AIR Cr-Mo | black silver

4x replacement pins

1x Allen key
